Loft Shop Access hatch Splayed Upstand With Dome
£757.00
Select a size
Select a option
 In Stock
 Next Working Day Delivery

Customer reviews
Sorry, no reviews available at the moment.


Roof Access Hatches

High quality thermoformed rooflights designed to make optimum use of natural light and to access your roof with ease.  The Loft Shop domes are offered in a wide range of sizes, shapes and glazing options to meet virtually any specifier and client requirements.


Key features include

  • Polycarbonate double skin
  • To BS 476: Part 3 AA rated
  • To BS 476: Part 7 Class 1
  • Compliant with HSG33 recommendations
  • Ventilation and access options available
  • Patented high security screwbolt fixing
  • Insulated and thermally broken upstand
  • Pre-finished interanally

You can also get a solid aluminium insulated cover which is fully insulated with a U value of 0.80 with superior noise insulation also. POA at 0208 551 5800



The Loft Shop roof domes are thermoformed from UV protected, co-extruded polycarbonate sheet and are available in single, double, triple quad skin or Eco multiwall construction.

Polycarbonate domes use a minimum 3mm thick glazing and have been tested and certified according to EN 1873: 1200 Joules, and ACR(M): 001: 2005 Class B.

Loft Shop roof domes are tested to the highest standards and are proven suitable for use on most flat roofs, including single ply, felt, hot-melt, asphalt, liquid, GRP and lead.  They are normally specified with our proprietary curbs but can also be installed on existing builder's curbs.

Higher security, access and ventilation options are available.

High security screwbolts

Unique to our roof domes, these are patented high security screwbolts, supplied factory fitted as standard to all units.  Once installed, the fixing cannot be removed using common tools.  The screwbolt provides high level of resistance to tampering or forced entry.  The fixing screw or bolt is sleeved within the body of the screwbolt which avoids pressure being exerted on the rooflight glazing as the fixing is tightened.  This virtually eliminates the risk of stress fractures caused by over-tightening.


Thermal Values

Double Skin

  • U-Value 2.9 W/m2K
  • Economical

Triple Skin

  • Best insulation U-Value 1.78 W/m2K
  • Better sound insulation
  • Complies with virtually all Building Regulations

For prices on the triple skin dome please ask for POA on 02208 551 5800


Products listed as NEXT WORKING DAY DELIVERY must be ordered before 1.00pm in order for them to be despatched the same day. Orders received after 1.00pm will be despatched the following working day.

Need any further advice? Call us now on 0870 604 0404
